Dellok ASTM A36 Grade B A106b A53 API 5L x70 x52 Seamless carbon steel pipe

Ask Lasest Price
Brand Name :	Dellok Yonghui
Model Number :	Non-Alloy
Price :	25 - 99 tons $600.00 >= 100 tons $500.00
Payment Terms :	T/T, L/C
Supply Ability :	5000 Ton/Tons per Month
Delivery Time :	5-9 calendar days
Certification :	ISO9001, API

Add to Cart

Product Details
Company Profile

Dellok ASTM A36 Grade B A106b A53 API 5L x70 x52 Seamless carbon steel pipe

Dellok ASTM A36 Grade B A106b A53 API 5L x70 x52 Seamless carbon steel pipe

About Us

^{DELLOK (YONGHUI RADIATING PIPE MANUFACTURING CO.,LTD.) was established in 2002, which is located in Jiangsu, China. After many years of development, the company now has 66 million yuan in fixed assets, more than 200 employees, and 33 technical staffs. We have 4 aluminum processing production lines, with the annual processing capacity of more than 20,000 tons; And we have 5 tube-drawing production lines; 47 fintube production lines, 1 imported production line from American with the brand of McElroy , with the annual production capacity of 12 million meters the above. Quality is the theme of eternal pursuit of winner -Production workshop- Meticulous works, standardized management system and systematic quality assurance are Dellok(YONGHUI)'s best commitment to quality. In Dellok(YONGHUI), the quality control is not only the detection of the final process, but throughout the entire production process. We implement a set of quality control and assurance systems. Each batch of pipes is sampled and tested, and records are kept as a quality guarantee for the final product.}

Dellok ASTM A36 Grade B A106b A53 API 5L x70 x52 Seamless carbon steel pipe

Product descriptions from the supplier

Dellok ASTM A36 Grade B A106b A53 API 5L x70 x52 Seamless carbon steel pipe

Size

^{Related Standard & Specification: API 5CT, ISO 11960, API 5B, GOST}

^{Related Grade: J55, K55, N80, L80-1, L80-9Cr, L80-13Cr, P110, Q125, K55 D10, L80 D10.}

^{Available Approved Marine: ABS / BV / LR / DNV / GL / KR, EN10204 3.2 MTC}

^{Special Service: Sweet Service, Sour Service, Anti-H2S, NACE MR0175/ISO15156}

^{Produce Process: Hot Rolled, Cold Drawn, Hot Expanded.}

^{Accessories: Pup Joint, Coupling (Coupling Stock), Blast Joint, Crossover etc.}

^{Connection: API connection and Premium connection, like TPCQ, HSM etc.}

API Casing
Size		Grade and Connection									Standards
OD mm (in)	WT/mm	H40	J55 K55	M65	L80-1 R95	N80-1 N80Q	C90 T95	C110	P110	Q125	Standards
114.3(4.5')	5.21	S	S	S							API SPEC 5CT/ISO11960
	5.69		S/B	S/B
	6.35		S/L/B	L/B	L/B	L/B	L/B		L/B
	7.37			L/B	L/B	L/B	L/B		L/B
	8.56								L/B	L/B
127(5')	5.59		S	S
	6.43		S/L/B	S/L/B
	7.52		S/L/B	L/B	S/L/B	S/L/B	L/B		S/L/B
	9.19			L/B	S/L/B	S/L/B	L/B		S/L/B	L/B
	11.1			L/B	L/B	L/B	L/B		L/B	L/B
	12.14				L/B	L/B	L/B		L/B	L/B
	12.7				L/B	L/B	L/B		L/B	L/B
139.7(5.5')	6.2	S	S	S
	6.98		S/L/B	S/L/B
	7.72		S/L/B	L/B	S/L/B	S/L/B	L/B		S/L/B
	9.17			L/B	S/L/B	S/L/B	L/B		S/L/B
	10.54			L/B	S/L/B	S/L/B	L/B		S/L/B	S/L/B
168.28(6.625')	7.32	S	S/L/B	S/L/B
	8.94		S/L/B	L/B	S/L/B	S/L/B	L/B		S/L/B
	10.59			L/B	S/L/B	S/L/B	L/B		S/L/B
	12.06				S/L/B	S/L/B	L/B		S/L/B	L/B
177.8(7')	6.91	S	S	S
	8.05		S/L/B	L/B	S/L/B	S/L/B	L/B
	9.19			L/B	S/L/B	S/L/B	L/B		S/L/B
	10.36			L/B	S/L/B	S/L/B	L/B		S/L/B
	11.51			L/B	S/L/B	S/L/B	L/B		S/L/B
	12.65				S/L/B	S/L/B	L/B		S/L/B	S/L/B
	13.72				S/L/B	S/L/B	L/B		S/L/B	S/L/B
193.68(7.625')	8.33		S/L/B	S/L/B	L/B	L/B	L/B
	9.52			L/B	L/B	L/B	L/B		L/B
	10.92			L/B	L/B	L/B	L/B		L/B
	12.7				L/B	L/B	L/B		L/B	L/B
	14.27				L/B	L/B	L/B		L/B	L/B
	15.11				L/B	L/B	L/B		L/B	L/B
	15.88				L/B	L/B	L/B		L/B	L/B
219.08(8.625')	6.71		S	S	S
	7.72	S	S/L/B	S
	8.94	S	S/L/B	S/L/B
	10.16			S/L/B	L/B	L/B	L/B		L/B
	11.43			L/B	L/B	L/B	L/B		L/B
	12.7				L/B	L/B	L/B		L/B
	14.15				L/B	L/B	L/B		L/B	L/B
244.48(9.625')	8.94	S	S/L/B	S/L/B
	10.03		S/L/B	S/L/B	L/B	L/B	L/B		L/B
	11.05			L/B	L/B	L/B	L/B		L/B
	11.99			L/B	L/B	L/B	L/B		L/B	L/B
	13.84				L/B	L/B	L/B		L/B	L/B
	15.11				L/B	L/B	L/B		L/B
273.05(10.75')	8.89	S/B		S/B
	10.16	S/B	S/B	S/B
	11.43	S/B	S/B	S/B	S/B	S/B	S/B		S/B
	12.57				S/B	S/B	S/B		S/B
	13.84						S/B		S/B	S/B
	15.11						S/B		S/B	S/B
298.45(11.75')	9.65
	10.92
	12.19				S/B				S/B
	13.06				S/B				S/B	S/B
339.72(13.375')	8.38	S
	9.65		S/B	S/B
	10.92		S/B	S/B
	12.19			S/B	S/B	S/B	S/B		S/B
	13.06				S/B	S/B	S/B		S/B	S/B
406.4(16')	16.66
508(20')	16.13		S/L/B
Note: S-SC;L-LC;B-BC.

API Tubing
Size		Grade and Connection							Standards
OD mm (in)	WT/mm	H40	J55	L80-1 R95	N80-1 N80Q	C90	T95	P110	Standards
42.16(1.66')	3.18								API SPEC 5CT/ISO11960
	3.56	N/U	N/U	N/U	N/U	N/U	N/U
	4.85	U	U	U	U	U	U	U
48.26(1.9')	3.18	N/U	N/U	N/U	N/U	N/U	N/U
	3.68	N/U	N/U	N/U	N/U	N/U	N/U
	5.08	U	U	U	U	U	U	U
	6.35
	7.62
60.32(2.375')	4.24
	4.83
	6.45
	7.49
	8.53
73.02(2.875')	5.51	N/U	N/U	N/U	N/U	N/U	N/U	N/U
	7.01			N/U	N/U	N/U	N/U	N/U
	7.82			N/U	N/U	N/U	N/U	N/U
	8.64				U			U
	9.96
	11.18	U	N	N	N	N	N
88.9(3.5')	5.49
	6.45	N/U	N/U	N/U	N/U	N/U	N/U	N/U
	7.34	N	N	N	N	N	N
	9.52			N/U	N/U	N/U	N/U	N/U
	10.92
	12.09
	13.46
101.6(4')	5.74	N	N	N	N	N	N	N
	6.65	U	U	U	U	U	U	U
	8.38
	10.54
	12.7
	15.49
114.3(4.5')	6.88	N/U	N/U	N/U	N/U	N/U	N/U	N/U
	8.56
	9.65
	10.92
	12.7
	14.22
	16
Note: N-NU; U-EU.

Chemical Analysis(%) For Part Standard
Standard	Class	Grade	Type	C		Mn		Mo		Cr		Ni	Cu	P	S	Si
Standard	Class	Grade	Type	min	max	min	max	min	max	min	max	max	max	max	max	max
	1	2	3	4	5	6	7	8	9	10	11	12	13	14	15	16
API 5CT	1	H40	-	-	-	-	-	-	-	-	-		-	0.03	0.03	-
		J55	-	-	-	-	-	-	-	-	-		-	0.03	0.03	-
		K55	-	-	-	-	-	-	-	-	-		-	0.03	0.03	-
		N80	1	-	-	-	-	-	-	-	-		-	0.03	0.03	-
		N80	Q	-	-	-	-	-	-	-	-		-	0.03	0.03	-
	2	M65	-	-	-	-	-	-	-	-	-		-	0.03	0.03	-
		L80	1	-	0.43	-	1.9	-	-	-	-	0.25	0.35	0.03	0.03	0.45
		L80	9Cr	-	0.15	0.3	0.6	0.9	1.1	8	10	0.5	0.25	0.02	0.01	1
		L80	13Cr	0.15	0.22	0.25	1	-	-	12	14	0.5	0.25	0.02	0.01	1
		C90	1	-	0.35	-	1.2	0.25	0.85	-	1.5	0.99	-	0.02	0.01	-
		C90	2	-	0.5	-	1.9	-	NL	-	NL	0.99	-	0.03	0.01	-
		C95	-	-	0.45	-	1.9	-	-	-	-	-	-	0.03	0.03	0.45
		T95	1	-	0.35	-	1.2	0.25	0.85	0.4	1.5	0.99	-	0.02	0.01	-
		T95	2	-	0.5	-	1.9	-	-	-	-	0.99	-	0.03	0.01	-
	3	P110		-	-	-	-	-	-	-	-		-	0.03	0.03	-
	4	Q125	1	-	0.35	-	1.35	-	0.85	-	1.5	0.99	-	0.02	0.01	-
		Q125	2	-	0.35	-	1	-	NL	-	NL	0.99	-	0.02	0.02	-
		Q125	3	-	0.5	-	1.9	-	NL	-	NL	0.99	-	0.03	0.01	-
		Q125	4	-	0.5	-	1.9	-	NL	-	NL	0.99	-	0.03	0.02	-
