    Dellok Extruded Finned Copper Tube Making Machine

    Ask Lasest Price
    Brand Name : Dellok Yonghui
    Model Number :
    Price : >= 1 sets $8,000.00
    Payment Terms : T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 5 Set/Sets per Month
    Delivery Time : 1-3 weeks
    Certification :
    • Product Details
    • Company Profile

    Dellok Extruded Finned Copper Tube Making Machine

    Dellok Extruded Finned Copper Tube Making Machine

    About us

    Professional heat exchanger factory with 20 years of experience, providing you with one-stop heat transfer solutions to design different heat exchangers according to your purposes (metallurgy, food, petrochemical, pharmaceutical, beverage, wastewater, refrigeration, etc...)

    Dellok Young is a professional manufacturer of various heat exchangers integrating R&D, design, production and sales. The heat exchangers produced are mainly used in petrochemical, electric power, papermaking, building heating, mining and other industries, such as air heaters, food industry plant protein powder, starch and other air heater spray drying systems.

    The company now has a professional technical innovation team and professional after-sales personnel. The company's production plant covers an area of approximately 18,000 square meters, has multiple professional and advanced CNC and automated production equipment, and has obtained a number of professional certificates and patents.
    The company has a professional foreign trade team and has trade cooperation with various regions. Some global partners conducted on-site inspections of the production plants and were very satisfied with the inspection results and established long-term strategic cooperative relationships with our company.

    Dellok Extruded Finned Copper Tube Making Machine

    Dellok Extruded Finned Copper Tube Making Machine Dellok Extruded Finned Copper Tube Making Machine


    MAIN TECHNICAL PARAMETERS

    The distance from center line of horizontal spindle to working table
    345mm
    Distance of work table above ground
    718mm
    Rotation speed of output shaft
    80rpm; 120rpm
    Diameter of blade shaft
    ф45mm
    Range of fin outside diameter
    Φ18-Φ70mm
    Minimal fin root diameter
    Φ15mm
    Range of fin pitch
    0-8.00mm
    Range of finned tube length
    0-15000mm
    Main motor power (optional)
    11KW
    Cooling pump model
    DB-25, 120W
    Machine weight
    1415kg
    External dimension (LxWxH)(mm)
    2150*760*1430


    -Tool holder and tool holder body adopt advanced dual-circular-key structure, big torque withstanding, accurate and reliable displacement.
    - Tool holder adopts split type design, convenient for blade debugging, cleaning & fixing.
    - Blade spindle bushing adopts special taper sliding bearings brings max. bushing utilization.
    - Universal joints and spindles are of spline linking; And coolant cooling tank is separate to main rolling machine.
    - Special extruding blade design, high efficient, long blade life.

    Dellok Extruded Finned Copper Tube Making Machine Dellok Extruded Finned Copper Tube Making Machine


    FAQ

    Q: What is the warranty for your products?

    A :We provide one year warranty for the products.

    Q: What payment terms do you accept?

    A :Trade assurance,TT,Western Union.

    Q: What are the modes of transportation of machines?

    A: Air freight, sea freight express delivery, etc. We will choose the most suitable transportation method according to your requirements.Low fin Tube
