Dellok hfw Casing Tube J55 N80 L80 P110 Q125 T95 C110 V140 V150

Ask Lasest Price
Brand Name :	Dellok Yonghui
Model Number :	High Frequency Weld (HFW,Solid)Fin Tube
Certification :	API 51
Payment Terms :	T/T, L/C, L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :	5-8 working days
Price :	5 - 9 metric tons $1,100.00 >= 10 metric tons $980.00
Supply Ability :	10000 Piece Monthly

Add to Cart

Product Details
Company Profile

Dellok hfw Casing Tube J55 N80 L80 P110 Q125 T95 C110 V140 V150

Dellok HFW Casing Tube J55 N80 L80 P110 Q125 T95 C110 V140 V150

^{Dellok(YONGHUI Radiating Pipe Manufacturing Co.,Ltd) was established in 2002, which is located in Nanjing, China.We joined HARBIN AIR CONDITIONING CO., LTD. in 2022 and became the most professional industry manufacturer in China. After many years of development, the company now has 66 million yuan in fixed assets, more than 200 employees, and 33 technical staffs. We have 4 aluminum processing production lines, with the annual processing capacity of more than 20,000 tons; And we have 5 tube-drawing production lines; 47 fintube production lines, 1 imported production line from American with the brand of McElroy , with the annual production capacity of 12 million meters the above.}

Dellok hfw Casing Tube J55 N80 L80 P110 Q125 T95 C110 V140 V150

Product Description

Output	3.5kw
Carrying	24kgs
Height	100m
Cable	Auto
Function	lighting
Power balance	Auto/Manual
Optical com	Optional
Anti-shock	Yes
Cooling	Normal
4g com	Optional
Material	Aluminum
Size	40x30x30cm
Weight	22kgs

Size

^{Related Standard & Specification: API 5CT, ISO 11960, API 5B, GOST}

^{Related Grade: J55, K55, N80, L80-1, L80-9Cr, L80-13Cr, P110, Q125, K55 D10, L80 D10.}

^{Available Approved Marine: ABS / BV / LR / DNV / GL / KR, EN10204 3.2 MTC}

^{Special Service: Sweet Service, Sour Service, Anti-H2S, NACE MR0175/ISO15156}

^{Produce Process: Hot Rolled, Cold Drawn, Hot Expanded.}

^{Accessories: Pup Joint, Coupling (Coupling Stock), Blast Joint, Crossover etc.}

^{Connection: API connection and Premium connection, like TPCQ, HSM etc.}

API Casing
Size		Grade and Connection									Standards
OD mm (in)	WT/mm	H40	J55 K55	M65	L80-1 R95	N80-1 N80Q	C90 T95	C110	P110	Q125	Standards
114.3(4.5')	5.21	S	S	S							API SPEC 5CT/ISO11960
	5.69		S/B	S/B
	6.35		S/L/B	L/B	L/B	L/B	L/B		L/B
	7.37			L/B	L/B	L/B	L/B		L/B
	8.56								L/B	L/B
127(5')	5.59		S	S
	6.43		S/L/B	S/L/B
	7.52		S/L/B	L/B	S/L/B	S/L/B	L/B		S/L/B
	9.19			L/B	S/L/B	S/L/B	L/B		S/L/B	L/B
	11.1			L/B	L/B	L/B	L/B		L/B	L/B
	12.14				L/B	L/B	L/B		L/B	L/B
	12.7				L/B	L/B	L/B		L/B	L/B
139.7(5.5')	6.2	S	S	S
	6.98		S/L/B	S/L/B
	7.72		S/L/B	L/B	S/L/B	S/L/B	L/B		S/L/B
	9.17			L/B	S/L/B	S/L/B	L/B		S/L/B
	10.54			L/B	S/L/B	S/L/B	L/B		S/L/B	S/L/B
168.28(6.625')	7.32	S	S/L/B	S/L/B
	8.94		S/L/B	L/B	S/L/B	S/L/B	L/B		S/L/B
	10.59			L/B	S/L/B	S/L/B	L/B		S/L/B
	12.06				S/L/B	S/L/B	L/B		S/L/B	L/B
177.8(7')	6.91	S	S	S
	8.05		S/L/B	L/B	S/L/B	S/L/B	L/B
	9.19			L/B	S/L/B	S/L/B	L/B		S/L/B
	10.36			L/B	S/L/B	S/L/B	L/B		S/L/B
	11.51			L/B	S/L/B	S/L/B	L/B		S/L/B
	12.65				S/L/B	S/L/B	L/B		S/L/B	S/L/B
	13.72				S/L/B	S/L/B	L/B		S/L/B	S/L/B
193.68(7.625')	8.33		S/L/B	S/L/B	L/B	L/B	L/B
	9.52			L/B	L/B	L/B	L/B		L/B
	10.92			L/B	L/B	L/B	L/B		L/B
	12.7				L/B	L/B	L/B		L/B	L/B
	14.27				L/B	L/B	L/B		L/B	L/B
	15.11				L/B	L/B	L/B		L/B	L/B
	15.88				L/B	L/B	L/B		L/B	L/B
219.08(8.625')	6.71		S	S	S
	7.72	S	S/L/B	S
	8.94	S	S/L/B	S/L/B
	10.16			S/L/B	L/B	L/B	L/B		L/B
	11.43			L/B	L/B	L/B	L/B		L/B
	12.7				L/B	L/B	L/B		L/B
	14.15				L/B	L/B	L/B		L/B	L/B
244.48(9.625')	8.94	S	S/L/B	S/L/B
	10.03		S/L/B	S/L/B	L/B	L/B	L/B		L/B
	11.05			L/B	L/B	L/B	L/B		L/B
	11.99			L/B	L/B	L/B	L/B		L/B	L/B
	13.84				L/B	L/B	L/B		L/B	L/B
	15.11				L/B	L/B	L/B		L/B
273.05(10.75')	8.89	S/B		S/B
	10.16	S/B	S/B	S/B
	11.43	S/B	S/B	S/B	S/B	S/B	S/B		S/B
	12.57				S/B	S/B	S/B		S/B
	13.84						S/B		S/B	S/B
	15.11						S/B		S/B	S/B
298.45(11.75')	9.65
	10.92
	12.19				S/B				S/B
	13.06				S/B				S/B	S/B
339.72(13.375')	8.38	S
	9.65		S/B	S/B
	10.92		S/B	S/B
	12.19			S/B	S/B	S/B	S/B		S/B
	13.06				S/B	S/B	S/B		S/B	S/B
406.4(16')	16.66
508(20')	16.13		S/L/B
Note: S-SC;L-LC;B-BC.

API Tubing
Size		Grade and Connection							Standards
OD mm (in)	WT/mm	H40	J55	L80-1 R95	N80-1 N80Q	C90	T95	P110	Standards
42.16(1.66')	3.18								API SPEC 5CT/ISO11960
	3.56	N/U	N/U	N/U	N/U	N/U	N/U
	4.85	U	U	U	U	U	U	U
48.26(1.9')	3.18	N/U	N/U	N/U	N/U	N/U	N/U
	3.68	N/U	N/U	N/U	N/U	N/U	N/U
	5.08	U	U	U	U	U	U	U
	6.35
	7.62
60.32(2.375')	4.24
	4.83
	6.45
	7.49
	8.53
73.02(2.875')	5.51	N/U	N/U	N/U	N/U	N/U	N/U	N/U
	7.01			N/U	N/U	N/U	N/U	N/U
	7.82			N/U	N/U	N/U	N/U	N/U
	8.64				U			U
	9.96
	11.18	U	N	N	N	N	N
88.9(3.5')	5.49
	6.45	N/U	N/U	N/U	N/U	N/U	N/U	N/U
	7.34	N	N	N	N	N	N
	9.52			N/U	N/U	N/U	N/U	N/U
	10.92
	12.09
	13.46
101.6(4')	5.74	N	N	N	N	N	N	N
	6.65	U	U	U	U	U	U	U
	8.38
	10.54
	12.7
	15.49
114.3(4.5')	6.88	N/U	N/U	N/U	N/U	N/U	N/U	N/U
	8.56
	9.65
	10.92
	12.7
	14.22
	16
Note: N-NU; U-EU.

Chemical Analysis(%) For Part Standard
Standard	Class	Grade	Type	C		Mn		Mo		Cr		Ni	Cu	P	S	Si
Standard	Class	Grade	Type	min	max	min	max	min	max	min	max	max	max	max	max	max
	1	2	3	4	5	6	7	8	9	10	11	12	13	14	15	16
API 5CT	1	H40	-	-	-	-	-	-	-	-	-		-	0.03	0.03	-
		J55	-	-	-	-	-	-	-	-	-		-	0.03	0.03	-
		K55	-	-	-	-	-	-	-	-	-		-	0.03	0.03	-
		N80	1	-	-	-	-	-	-	-	-		-	0.03	0.03	-
		N80	Q	-	-	-	-	-	-	-	-		-	0.03	0.03	-
	2	M65	-	-	-	-	-	-	-	-	-		-	0.03	0.03	-
		L80	1	-	0.43	-	1.9	-	-	-	-	0.25	0.35	0.03	0.03	0.45
		L80	9Cr	-	0.15	0.3	0.6	0.9	1.1	8	10	0.5	0.25	0.02	0.01	1
		L80	13Cr	0.15	0.22	0.25	1	-	-	12	14	0.5	0.25	0.02	0.01	1
		C90	1	-	0.35	-	1.2	0.25	0.85	-	1.5	0.99	-	0.02	0.01	-
		C90	2	-	0.5	-	1.9	-	NL	-	NL	0.99	-	0.03	0.01	-
		C95	-	-	0.45	-	1.9	-	-	-	-	-	-	0.03	0.03	0.45
		T95	1	-	0.35	-	1.2	0.25	0.85	0.4	1.5	0.99	-	0.02	0.01	-
		T95	2	-	0.5	-	1.9	-	-	-	-	0.99	-	0.03	0.01	-
	3	P110		-	-	-	-	-	-	-	-		-	0.03	0.03	-
	4	Q125	1	-	0.35	-	1.35	-	0.85	-	1.5	0.99	-	0.02	0.01	-
		Q125	2	-	0.35	-	1	-	NL	-	NL	0.99	-	0.02	0.02	-
		Q125	3	-	0.5	-	1.9	-	NL	-	NL	0.99	-	0.03	0.01	-
		Q125	4	-	0.5	-	1.9	-	NL	-	NL	0.99	-	0.03	0.02	-

Tensile Property For Part Standard
Standard	Class	Grade	Type	Elongation(%)	Yield Strengh(Mpa)		Tensile Strengh(Mpa)	Hardness(Max)		Required WT	Allowed Tolerance of Hardness
					Min	Max	Min	HRC	HBW/-	mm	HRC
	1	2	3	4	5	6	7	8	9	10	11
API 5CT	1	H40		0.5	276	552	414	-	-	-	-
		J55	-	0.5	379	552	517	-	-	-	-
		K55	-	0.5	379	552	655	-	-	-	-
		N80	1	0.5	552	758	689	-	-	-	-
		N80	Q	0.5	552	758	689	-	-	-	-
	2	M65	-	0.5	448	586	586	22	235	-	-
		L80	1	0.5	552	655	655	23	241	-	-
		L80	9Cr	0.5	552	655	655	23	241	-	-
		L80	13Cr	0.5	552	655	655	23	241	-	-
		C90	1,2	0.5	621	724	689	25.4	255	≤12.70	3
		C90	1,2	0.5	621	724	689	25.4	255	12.71~19.04	4
		C90	1,2	0.5	621	724	689	25.4	255	19.05~25.39	5
		C90	1,2	0.5	621	724	689	25.4	255	≥25.40	6
		C95	-	0.5	655	758	724	-	-	-	-
		T95	1,2	0.5	655	758	724	25.4	255	≤12.70	3
		T95	1,2	0.5	655	758	724	25.4	255	12.71~19.04	4
		T95	1,2	0.5	655	758	724	25.4	255	19.05~25.39	5
		T95	1,2	0.5	655	758	724	25.4	255	≥25.40	6
	3	P110	-	0.6	758	965	862	-	-	-	-
	4	Q125	1~4	0.65	862	1034	931	-	-	≤12.70	3
		Q125	1~4	0.65	862	1034	931	-	-	12.71~19.04	4
		Q125	1~4	0.65	862	1034	931	-	-	≥19.05	5

FAQ

^{1.Does tubing fit inside casing?
Tubing has a smaller outer diameter than the inner diameter of casing,therefore tubing can fit inside casing.4 1/2 inches is the threshold for maximum tubing size or minimumcasing size.}

^{2.How much does steel casingpipe cost?
Steel Casing Pipe cost is lower than drill pipe or the OCTG tubing cost, it is usually higher 200 USD than the regular API 5L pipe.}
