    DELLOK High Pressure Annealed SA192 Carbon Steel Fin Tube Seamless

    Ask Lasest Price
    Brand Name : DELLOK
    Model Number : Flat tube
    Certification : CE. ISO,EN10204. 3.1 Cert.
    Price : N/A Contact us for details
    Payment Terms : L/C, T/T Contact us for details
    Supply Ability : 60000 meters month
    Delivery Time : Ex-work within 4 or 5 weeks after order
    • Product Details
    • Company Profile

    DELLOK High Pressure Annealed SA192 Carbon Steel Fin Tube Seamless

    High Pressure Annealed SA192 Carbon Steel Seamless Tube


    A192 / SA192 Annealed Seamless Carbon Steel / Pipe For High-Pressure Service


    Product Details

    Tube details:

    Tube OD: 12.7mm – 114.3mm

    Wall Thickness: 0.8mm - 15mm

    Length: Fixed(6m,9m,12,24m) or normal length(5-12m)

    Standard: ASTM A192, A192M


    Description:

    ASTM ASTM A192, A192M

    Seamless Carbon Steel Boiler Tubes For High-Pressure Service.


    Steel Grde:
    Grade A192

    Packing:
    Beveled/black painting/ plastic caps/ in bundles/ steel strips/ wooden protection

    Inspection and Test:
    Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength, Yield Strength,Elongation, Flaring, Flattening, Bending, Hardness, Impact Test),Surface and Dimension Test,Nodestructive Test, Hydrostatic Test.

    Surface treatment:
    Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting

    Mark:
    As requested.


    Delivery Condition:

    Annealed, Normalized, Normalized and Tempered


    Chemical composition:

    Product

    Ttem

    Grade

    Chemical composition

    C

    Si

    Mn

    P.≤

    S.≤

    Cr

    Ni

    others

    Carbon steel

    1

    10

    0.07/0.13

    0.17/0.37

    0.35/0.65

    0.03

    0.03

    ≤0.15

    ≤0.30

    Cu≤0.25

    2

    20

    0.17/0.23

    0.17/0.37

    0.35/0.65

    0.03

    0.03

    ≤0.25

    ≤0.30

    Cu≤0.25

    3

    A179

    0.06/0.18

    -

    0.27/0.63

    0.03

    0.03

    -

    -

    -

    4

    A192

    0.06/0.18

    ≤0.25

    0.27/0.63

    0.03

    0.03

    -

    -

    -


    Mechanical properties:

    Item

    Mark

    Tensile property

    Hardness

    Extension strength Rm Mpa

    Lower Yield strength Rel or Rp0.2 MPa

    lower Yield strength ReL or Rp0.2 Mpa

    Thickness

    Thickness

    ≤16

    >16

    <5.1

    ≥5.1

    1

    10

    335~475

    205

    195

    24

    -

    -

    2

    20

    410~530

    245

    235

    20

    -

    -

    3

    A179

    ≥325

    180

    35

    -

    -

    4

    A192

    ≥325

    180

    35

    77HRB

    137HB


    Applications:

    1,For evaporator, heat exchangers, condensers, heat transfer equipment and similar pipes.

    2,Widely used in the mechanical treatment field, petrochemical industry, transport and construction field

    3,Ordinary structural purposes and mechanic structural purposes, for example in construction field, fulcrum bearing etc;

    4,The transportation of fluids in the projects and big equipments, for example transport of water, oil, gas etc

    5,Can be used in low and medium pressure boiler for the transportation of fluids, for example steam tube, big smoke tube, small smoke tube, generating tube etc
