    DELLOK A213 Alloy Steel Oil Refinery T5 T9 T11 SMLS Studded Pipe

    Ask Lasest Price
    Brand Name : DELLOK
    Model Number : Studs
    Certification : CE. ISO,EN10204. 3.1 Cert.
    Price : N/A Contact us for details
    Payment Terms : L/C, T/T Contact us for details
    Supply Ability : 60000 meters month
    Delivery Time : Ex-work within 5 weeks after order.
    • Product Details
    • Company Profile

    DELLOK A213 Alloy Steel Oil Refinery T5 T9 T11 SMLS Studded Pipe

    A213 Alloy Steel Oil Refinery T5 T9 T11 SMLS Studded Pipe


    A213 T5 / T9 / T11 / T12 SMLS alloy steel , NPS 3''(88.9mm) studded tubes for oil refinery​


    ASTM A213 / A213M :

    Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes


    Manufacturing process:

    Studs are fully automatically welded onto the tube by resistance welding. It include two types :Cylindrical or elliptical. And we can provide the raw materials mill certificates, inspection and test samples results and warranty certificate of manufacturer.


    Acceptance criteria

    Approved drawings and the delivery conditions (TDC) of clients.


    Delivery condition

    Tube ends are square cut, free burrs, internally dried and air blown clean, externally coated with varnish at both ends of extruded bimetallic fin tube.

    surface with Oil dip, black coating or varnish.


    Applications:

    1. Furnace

    2. Chemical

    3. Petrochemical industry

    4. Power station etc.

    Product Details

    Material:

    Carbon, stainless, and alloy steels.

    Tube details:

    Tube Thickness:4mm~15mm

    Tube Length:16 meters max

    Tube OD: 219 mm max

    Studs Height:10mm Min.

    Studs OD:OD6mm~OD16mm

    Production Capacity:

    Daily capacity up to 80,000 studs;


    Executive Standard

    ASTM A213/A213M

    Materials Grade

    T2, T5, T5b, T5c, T9, T11, T12, T17, T21, T22, T23, T24, T36, T91, T92, T122, T911


    Material Grade and Chemical Composition(%):

    Grade

    C

    Mn

    P≤

    S≤

    Si

    Cr

    Mo

    V≥

    T11

    0.05-0.15

    0.30-0.60

    0.025

    0.025

    0.50-1.00

    0.50-1.00

    1.00-1.50


    T12

    0.05-0.15

    0.30-0.61

    0.025

    0.025

    ≤0.50

    0.80-1.25

    0.44-0.65


    T13

    0.05-0.15

    0.30-0.60

    0.025

    0.025

    ≤0.50

    1.90-2.60

    0.87-1.13


    T2

    0.10-0.20

    0.30-0.61

    0.025

    0.025

    0.10-0.30

    0.50-0.81

    0.44-0.65


    T5

    ≤0.15

    0.30-0.60

    0.025

    0.025

    ≤0.50

    4.00-6.00

    0.45-0.65


    T5b

    ≤0.15

    0.30-0.60

    0.025

    0.025

    1.00-2.00

    4.00-6.00

    0.45-0.65


    T5c

    ≤0.12

    0.30-0.60

    0.025

    0.025

    ≤0.50

    4.00-6.00

    0.45-0.65


    T9

    ≤0.15

    0.30-0.60

    0.025

    0.025

    0.25-1.00

    8.00-10.00

    0.9-1.0


    T22

    0.05-0.15

    0.30-0.60

    0.025

    0.025

    ≤0.50

    1.90-2.60

    0.87-1.13


    T91

    0.08-0.12

    0.30-0.60

    0.020

    0.010

    ≤0.50

    8-9.50

    0.85-1.05

    0.18-0.25

    T92

    0.07-0.13

    0.30-0.60

    0.020

    0.010

    ≤0.50

    8-9.50

    0.3-0.60

    0.15-0.25

    T21

    0.05-0.15

    0.30-0.60

    0.025

    0.025

    ≤0.50

    2.65-3.35

    0.80-1.06



    Specifications:

    Items

    General Materials

    Popular ASTM /ASME Materials

    Core Tube Material

    Carbon Steel

    Alloy Steel

    Heat Resistant Steel,

    Stainless Steel

    1. Carbon Steel: A106 Gr. B

    2. Stainless Steel: TP304/304L,TP316/TP316L, TP347

    3. Alloy Steel: P5,T5,P9,T9,T11,T22

    Studs

    Material

    Carbon Steel

    Stainless Steel

    1. Carbon Steel

    2. Stainless Steel:

    TP409/410,TP304/304L,TP316/TP316L, TP321/TP321L


    Dimensions Data Sheet We're Supplying.

    General Descriptions of Studded tubes

    Popular Specifications we make

    Tube OD(mm)

    OD38mm~OD219mm

    Tube Wall Thickness(mm)

    4mm~15mm

    Tube Length(mm)

    16,000mm Max.

    Studs OD(mm)

    OD6mm~OD16mm

    Studs Height(mm)

    10mm~45mm

    Please email us for more information as your request.


    Competitive Advantage:

    1. We have more than 10,000 square meters workshop, including 3 finning machines, daily extrusion capacity up to 80,000 studs.

    2. Shanghai Port is our nearest seaport and airport, less than 2 hours’ drive away from our workshop, convenient transportation.

    3. Due to their high rigidity, studded tubes can be used even under extreme temperature and pressure conditions.
